Product

MAX300 drawbar trailer

2-3 central axles

Pneumatic suspension

17,5" tires

Your drawbar trailer for the daily construction work

With its compact design, the MAX300 drawbar trailer is suitable for the transportation of smaller and medium sized plant machinery.

Our central-axle trailer in tandem or tridem design offers you comfortable manoeuverability on winding and narrow construction sites.

It is a trailer type that is easy to reverse. The lightweight construction allows you to load more on your MAX300.

Due to the low loading floor, challenges with higher loads are resolved successfully.

The hydraulically controlled ramps enable an easy and safe loading process. Many lashing points stand for maximum security.

The MAX300 series has air suspension and a standard width of 2,540 mm for it's 3-axle version. The tandem trailer is only 2,480 mm wide.

The drawbar trailers are suitable for the following field:

Availability

Request an offer for your vehicle

Find vehicles which are immediately available

Configure your trailer fast and easy

USEFUL FEATURES TO FACILITATE YOUR DAILY WORK

The low construction height with 17,5" tires allows you to transport higher loads.

Single and double ramps offer you an easy access for machinery.

Lashing rings ensure optimal load security. The loading platform contains several lashing rings, which are foldable inwards and outwards.

1,750 mm long drawbar with a towing eye available in different diameters: 50 mm, 57 mm or 68 mm.

CLEVER OPTIONS TO BUILD UP YOUR TRAILER

Galvanised outriggers are extendable up to ca. 230 mm per side. Hardwood timber is used for the outriggers.

Pockets for stakes in the outer frame of the loading platform.

Foldable or pluggable alu-sideboards in the loading area.

Square iron ledges every 200 mm of the beavertail of the loading platform.

Lockable tool-box made out of HDPE or stainless steel under the loading platform.

Galvanised storage under the loading platform.

Lift-axle for the 3-axle version for less tire wear depending on the load.

Hydraulic landing gears for the 3-axle version for a comfortable and safe loading process.

Storage room for stakes.

WADER container locks incorporated into the loading platform.
